Compact Drone Surveillance Device & Long-Battery Detection Gear

1 / 5

Compact Drone Surveillance Device & Long-Battery Detection Gear

Customization:	Available
Frequency Range:	900MHz1.4GHz2.4GHz5.2GHz5.8GHz Customization
Frequency:	2.4GHz5.8GHz

Send Inquiry

Product Description

Basic Specifications

Model NO.

HR3

Application

Drone

Name

Portable Drone Detection and Positioning All-in-one

Detection Bands

900MHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz

Airspace Coverage

360° Full-Range Detection

Battery Life

12+ Hours Runtime

Protection

IP66 Waterproof & Dustproof

Dimensions

170mm × 85mm × 55mm

Product Description

The HD-R5 is a cutting-edge portable solution designed for intelligent drone surveillance and positioning. Engineered for security agencies, critical infrastructure protection, and event management, this all-in-one device combines passive detection, multi-target tracking, and precise identification to safeguard airspaces against unauthorized drone intrusions.

Core Features

🛡️

Passive Detection Technology: Receives electromagnetic signals without emitting radiation, ensuring zero impact on the environment. Ideal for sensitive areas.

📍

Comprehensive Tracking: Simultaneously tracks trajectories of over 20 drones and 10 pilots, displaying real-time flight paths on an integrated map.

🔍

Precision Identification: Distinguishes drones by brand, model, frequency, and unique electronic fingerprint ID (SN).

Technical Performance

Frequency Range	25MHz~6000MHz (customizable)
Detection Sensitivity	≤-105dBm (at 1040MHz)
Positioning Accuracy	≤1m (Drone), ≤1.5m (Pilot)
Detection Success Rate	≥99% Under Ideal Conditions
Deployment Time	≤90s Setup / ≤20s Withdrawal

Drone Compatibility & Reliability

Supports comprehensive detection of major brands: DJI (Mavic, Air, Mini, Phantom, Inspire), Autel, Hubsan, EHang, Yuneec, Xiaomi, Parrot, and 30+ other manufacturers.

Tested for harsh environments: Electrostatic discharge immunity, salt spray resistance, vibration resistance, and extreme temperature operations (-40ºC to 65ºC).

Frequently Asked Questions

Q: What is the maximum detection range of the HD-R5? A: The detection radius is typically 0~5km+, depending on the environment and drone type.

Q: Does the device interfere with other communication signals? A: No, it uses passive detection technology which receives signals without emitting radiation.

Q: How many targets can be tracked simultaneously? A: It can track over 20 drones and 10 pilot trajectories at the same time.

Q: Is the device suitable for outdoor use in rain? A: Yes, the device is rated IP66 waterproof and dustproof for rugged environmental resistance.

Q: How long does the battery last? A: The built-in lithium battery provides over 12 hours of continuous runtime.

Q: Can it identify specific drone models? A: Yes, it identifies drones by brand, model, and unique electronic fingerprint ID (SN).
