EPS Cement Sandwich Panel (also known as EPS Core Sandwich Panel or Lightweight Insulated Wall Panel) is a high-performance prefabricated building material composed of:
This panel is widely used in residential, commercial, and industrial construction due to its lightweight, fire resistance, thermal insulation, and rapid installation benefits.
| Parameter | Value / Description | Testing Standard |
|---|---|---|
| Panel Thickness | 50mm - 200mm (customizable) | ASTM C1289 |
| Panel Size | 1200mm × 2400mm (standard) | ISO 8335 |
| Density (EPS Core) | 18-30 kg/m³ | ASTM D1622 |
| Thermal Conductivity | 0.033-0.038 W/(m·K) | ASTM C518 |
| Fire Rating | Class A (Non-combustible) | EN 13501-1 |
| Sound Insulation | 40-45 dB (for 100mm) | ISO 10140 |
| Weight | 15-25 kg/m² | - |
| Feature | EPS Sandwich Panel | Brick Wall | Concrete Panel |
|---|---|---|---|
| Weight (kg/m²) | 15-25 | 180-220 | 200-250 |
| Thermal Insulation | Excellent | Poor | Moderate |
| Installation Time | 1-2 days per house | 2-4 weeks | 3-6 weeks |
| Cost Efficiency | 30% cheaper | High labor cost | High material cost |
We are a distinguished high-tech enterprise specializing in the advanced research, meticulous production, and exceptional construction services of sustainable, environmentally friendly, and energy-efficient wall materials. Our expansive facility spans 20,000 square meters, featuring a state-of-the-art production area. With an impressive annual output capacity surpassing 1 million square meters of lightweight, energy-saving composite wall panels, we are committed to excellence.
We proudly adhere to the most esteemed benchmarks including ISO 9001, CE, SGS, ASTM, and EN standards. Our commitment to sustainability is underscored by prestigious Green Building Certifications such as LEED and BREEAM.
It is a composite building material featuring two layers of fiber cement or calcium silicate boards with an expanded polystyrene (EPS) foam core. It is lightweight, fire-resistant, and provides excellent thermal and acoustic insulation.
Yes. The cement surface provides Class A fire resistance. The EPS core has a closed-cell structure with a low water absorption rate, making the entire panel moisture-proof and suitable for various climates.
Absolutely. The flexible EPS core helps absorb vibrations, making it an excellent choice for earthquake-prone areas compared to traditional rigid brick walls.
EPS panels allow for modular construction which is significantly faster. One house can be assembled in 1-2 days, reducing labor costs by up to 30% and overall project timelines by weeks.
Under normal conditions and with proper maintenance, EPS cement sandwich panels can last over 50 years. They are resistant to aging, corrosion, and biological degradation.
Yes, we support customization for lengths and thicknesses (standard range 50-200mm). Surface finishes can also be adapted to include colored coatings or specific textures.
